A mixing pump features a stirring device at the front of the pump’s suction port. This device agitates concentrated sewage, diluting it and drawing it into the pump body before discharge. It’s suitable for applications with high silt content, shallow water levels, and construction sites.
Power: 0.75-800 kW
Head: 1-60 m
Flow rate: 3-20,000 m³/h
Product Overview
The JYWQ series automatic mixing submersible sewage pump is a new environmentally friendly product developed by our company by integrating advanced technologies from similar products both domestically and internationally. Based on extensive feedback from pump experts and numerous improvements, our company has successfully developed this product. Its performance indicators meet or exceed those of similar products. The agitator and main impeller rotate synchronously, thoroughly stirring up sediment from the bottom of the pond and pumping it away, reducing the inconvenience of manual desilting. It is suitable for desilting fish ponds and cleaning septic tanks. The pump flange is manufactured to PN6.0 (6 kg) pressure, making it suitable for connection to engineering pipelines. It can be equipped with an automatic coupling device, making it more convenient to use in polluted, toxic, or oxygen-deficient environments.
Main Applications
This series of electric pumps is widely suitable for the discharge of heavily polluted industrial and commercial wastewater, urban sewage treatment plant systems, residential sewage stations, civil air defense system stations, hospital and hotel sewage discharge, municipal engineering projects, construction sites, exploration and mining auxiliary equipment, rural biogas pond irrigation, and Bailai Water Plant water supply systems.
Usage Conditions
· Medium temperature not exceeding +40°C
· Medium pH between 4 and 10
· Medium density not exceeding 1.2 x 103 kg/m3
· Power supply frequency 50 Hz
· Submersible depth not exceeding 5 meters
Supporting Electric Cabinet Options
Auto-coupling step-down starter cabinet, soft starter control cabinet, variable frequency control cabinet, ultrasonic level meter, and PLC system
Technical Patents
KLS Pump Industry Co., Ltd. is a large-scale pump company integrating manufacturing, technology research and development, and project design. With over 40 years of product technology experience, we have introduced advanced domestic and international technologies and production equipment, continuously innovated in product research and development, and developed a variety of new submersible pumps. These include: an automatically adjustable deep-well submersible pump, a mobile submersible mixed-flow pump with floating function, a high-lift submersible electric pump for deep wells, a mid-suction submersible mixed-flow pump, a submersible axial-flow pump with a sealing and anti-blocking mechanism, a water-lifting mid-suction submersible axial-flow pump, and a heat-resistant and corrosion-resistant submersible pump. All of these pump products have been granted utility model patents.
KLS PUMP boasts a large-scale test bench, laboratory, pump production ERP system, comprehensive data analysis server, and TP automated testing system. Leveraging its robust factory, technology, power supply equipment, and advanced testing equipment, test benches, and laboratories, Tianya Pump Industry has pioneered the concept of customized DIY production. KLS PUMP offers customized design solutions and customized pump production tailored to specific water environments, engineering environments, and complex environments.
